4000TL-Robotic Top Load Case Packer

Request More Information ›

The 4000TL Robotic Top Load Packer features a FANUC M-710iC/50 FP robot with versatile end-of-arm tool options to meet your product needs. This top load packaging solution offers flexible case and product size configurations, allowing for quick pattern changes via an intuitive HMI.

The 4000TL-Robotic offers high added safety features to ensure that both products and operators are safe throughout the packaging process.

  • Designed for a variety of flexible packages.
  • Easily accommodates any type of product: standing up, laying down, single file or multi-stream infeeds.
  • A good solution for contract packers, specialty product makers, limited time offers and new product launches.
  • Occupies similar floor space as hand pack operations, with the added benefit of fully automatic performance.
  • Up to 12 picks per minute with a wide case range.
  • Best Suited For Applications

    Away-From-Home (AFH), jumbo roll tissue (JRT), hard wound towel (HWT), diaper, feminine care, incontinence products

  • Speed

    Up to 12 picks per minute

  • Compact Footprint

    Reduce operational costs with a compact machine that can also be easily integrated

  • Ergonomic

    Designed to have easy access points for maintenance and cleaning

  • HMI

    10" HMI for simple and operator friendly touchscreen interface

  • Flexible

    Wide product and case size range that can handle a variety of pack patterns

  • Industrial Construction

    Robust tube framing with automotive finishing

  • Changeover

    Under 15 minutes

  • Infeed Conveyors

    Install an infeed conveyor to eliminate the manual process

  • Inspection Systems

    Ensure that all packages are packed properly with a secondary inspection system to eliminate operator errors

  • Lane Diverters

    Edson's lane diverters are designed to keep your lines organized and efficient, for product cumulation up to 5 lanes

  • Checkweighing

    Keep all your packaged products consistent with a weight system

  • Product Orientation Systems

    Edson's product orientation systems keep your products properly oriented for extra safety and security

  • Palletizing

    Integrate with a Brenton palletizer for a complete automated process

  • Pallet conveying

    With a automated pallet conveying process, operators can be freed up to other lines or areas of the plant

  • Stretch Wrapping

    Integrate with an Orion stretch wrapper for secure pallet wrapping to ensure your packages are protected while shipping

  • Case Types

    RSC, HSC, optional trays

  • Machine Footprint

    8' x 15'

  • Case Length

    10" - 30"

  • Case Width

    10" - 18"

  • Case Height

    Up to 18" including flaps
